Core P5 Core P5 Core P5 Core P5 Core P5 Core P5 Core P5
Core P5

Core P5

Out of stock
P/N
CA-1E7-00M1WN-00
USD$149,99
Thermaltake Core P5 ATX Open Frame panoramic viewing gaming computer case with Tt LCS Certified

Thermaltake Core P5 ATX Wall-Mount Chassis

Take presentation to the next level with the Core P5 Open Frame chassis by Thermaltake. The fully modular design of the Core P5 allows flexibility for 3-way placement layouts (Wall mount, Horizontal and Vertical), dual GPU layout locations: Horizontal and Vertical and placement locations for liquid cooling components. Uncover greatness with the Core P5’s panoramic viewing angle with its large acrylic window to protect and present. Seeing is believing, the Core P5 brings the ultimate in PC hardware viewing wherever you mount or display.

*A standard riser cable is included.

*The image is for reference only.

Tt LCS Certified

Tt LCS Certified is a Thermaltake exclusive certification applied to only products that pass the design and hardcore enthusiasts standards that a true LCS chassis should be held to. The Tt LCS certification was created so that we at Thermaltake can designate to all power users which chassis have been tested to be best compatible with extreme liquid cooling configurations to ensure you get the best performance from the best features and fitment.

Built for Makers

By practicing and incorporating the ideas of the “maker movement”, Thermaltake has designed the Core P5. The Core P5 is an an open frame chassis that anyone can access to do his or her own mods. This open frame chassis lets users map out and design their own build featuring whatever components they would like to use.

Users can download design files for the Core P5 on our microsite allowing them to customize their own mods.
Check more on 3DMarkers Site

3-Way Placement Layout

The Core P5 wall-mount chassis is designed for use in three different ways: Wall-mount, vertical, and horizontal placement. Built for customization that reflects the makers’ personality, it allows for adjustments to the look of the chassis while ensuring outstanding cooling performance.

Users can hang it on the wall as decoration, take it to wherever they want and display their builds vertically or horizontally.

Panoramic Viewing

Other cases on the market still have “ends” on their open frame designs, while the Core P5 is a true wall-mount case capable of showing the front and back full sides. The Core P5 is unlike anything on the market that is not a modded design or scratch build.

Supreme Liquid-Cooling Support

Core P5 wall-mount chassis enables users to build a complete high-end system, whilst supporting up to either 480mm radiator liquid cooling, or 140mm case fans, with a long graphic card at the same time, and simultaneously providing the best visual effects as well as increasing the CPU’s case modding potential. Most importantly, it has the capability to deliver an outstanding cooling efficiency throughout the entire case.

Versatile GPU & PSU Orientation

Show off your graphic card and power supply with our special design bracket. The Core P5 has included a standard riser cable for you to choose the way you want to build the system. Further, the Core P5 also has the support for vertical PSU layout when ITX motherboard is applied.

Thermaltake TT Premium PCI-E 3.0 Extender (Optional) – Supports a wide range of GPU solutions with ultra-excellent quality. Features like, extreme high-speed cable with highly-routable design, EMI shielding with conducting polymer are crafted for meeting the most demanding system. Available in 300mm, 600mm and 1000mm length.
Learn More

*Thermaltake makes no representation or warranty that the included standard riser cable will be suitable for any specified computer system without further testing. If you need any technique supports, please contact Thermaltake Global Service Center.

AIO Bracket (Optional)

Make your Core P5 stand out in the crowd. Build it up with the new Thermaltake AIO bracket, designed to support the AIO liquid cooling system and HDD expansion. The Core P5 can hold up to three brackets, and a single AIO bracket can support one 120mm or 140mm fan.
Learn More

Core P5 Radiator Supporting List

Radiator Compatibility List
  120
mm
140
mm
240
mm
280
mm
360
mm
420
mm
480
mm
L-Side * * * * * * *

Core P5 Fan Supporting List

Thermaltake Fan Compatibility List
  120mm 140mm
Pure Fan Series * *
Luna Fan Series * *
Riing Fan Series * *

※ Optional bracket is available for AIO installment

Core P5 Wall-Mounting Support

It’s an optional feature that wall-mounting parts are not included. See the picture on the left-hand side or download the Core P5 manual under “Support”.

More Information
P/N CA-1E7-00M1WN-00
Series Core
Model Core P5
Case Type Mid Tower
Dimension (H x W x D) 608 x 333 x 570 mm
(23.9 x 13.1 x 22.4 inch)
Net Weight 12.2 kg / 26.9 lb
Side Panel Transparent Window
Color Black
Material SPCC
Drive Bays
-Accessible
-Hidden
-Accessible : 1 x 3.5’’ or 2.5’’ (HDD tray)
-Hidden : 3 x 3.5’’ or 2.5’’ (Behind the M/B tray)
Expansion Slots 8
Motherboards 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
I/O Port USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1
PSU Standard PS2 PSU (optional)
Fan Support Left Side:
4 x 120mm
3 x 140mm
Radiator Support Left Side:
1 x 480mm
1 x 420mm
Clearance CPU cooler height limitation:
180mm

VGA length limitation:
280mm (With Reservoir)
570mm (Without Reservoir)

PSU length limitation:
200mm
