Thermaltake Core P90 Tempered Glass Edition Mid-Tower Chassis
Thermaltake has kicked open-frame chassis up to a notch and
presented the
Core P90 Tempered Glass Edition Mid-tower Chassis. The Core P90 TG boasts the case structure
split into three
compartments for graphic card, PSU and other cooling components. The triangular prism shaped
body and two 5mm
thick tempered glass side panels turn the Core P90 into a hexagonal prism outlined creature,
allowing for an
ultimate system display from every angle. Along with its 3-way placement layouts (wall
mountable, horizontal
laying and vertical standing), 7 drive bays with modular drive trays design and high liquid
cooling system
expandability, the Core P90 TG permits users upgraded aesthetics and limitless potential
with how they want to
configure their systems.
*A PCI Express Extender Cable is included.
*The image is for reference only.
Tt LCS Certified
Tt LCS Certified is a Thermaltake exclusive certification applied to only products that pass the design and hardcore enthusiast standards that a true LCS chassis should be held to. The Tt LCS certification was created so that we at Thermaltake can designate to all power users which chassis have been tested to be best compatible with extreme liquid cooling configurations to ensure you get the best performance from the best features and fitment.
A New Angle to PC Gaming
Build from a different angle, isolating components for improved heat dissipation to give each component proper spacing for optimal cooling performance. Present and protect each side with 5mm thick tempered glass panels and extended glass mounts allow easy to clean maintenance.
3-Way Placement Layout
Supporting 3-way placement layouts (Wall-mount, Vertical and Horizontal) angle your PC in multiple ways to accommodate users for a variety of configurations. With an Angled frame design, fit your PC like never before with the Core P90.
Make the Move to Modular Design
The Core P90 enables users to freely build their system
from the ground up
with modular panels, racks, brackets, and pre-design mounting arrays. No more unreachable
screw corners or
gaps to enjoy even more space for your precious parts during installation or maintenance.
3.5” or 2.5” HDD Drive Compatible
Extended Hardware Support
Supporting up to standard ATX form factor motherboards, go big with cooling fitment for CPU coolers up to 180mm in height, VGA lengths up to 320mm and PSU sizes up to 220mm in length. Add even more storage with up to 7 drive locations for 3.5” or 2.5” devices to lock and load games and media enthusiast look for.
AIO/DIY Liquid Cooling Capable
The Core P90 features an open frame installation space for advanced AIO/DIY liquid cooling components. Natively support all types of AIO liquid cooling solutions and capability to house up to 480mm DIY liquid cooling radiator fitment. Extend your GPU performance with virtually no limit to GPU sizes, especially when going vertical, and angled frame design brings a new direction to custom tube runs for a fresh presentation.
*The image is for reference only.
Go Vertical with your GPU and PSU
Including the TT Gaming PCI-E 3.0 Riser Cable, choose the
way you want to
display your graphics card and display your power like never before, vertically, to show off
all that colorful
power.
Thermaltake TT Premium PCI-E 3.0 Extender (Optional) – Supports a wide range of GPU
solutions with
ultra-efficient standards. Gain a strong connection with a high-speed, flexible design, EMI
shielding with
conducting polymer are crafted for meeting the most demanding system. Available in 300mm,
600mm and 1000mm
length.
Learn More
*Thermaltake makes no representation or warranty that the included standard riser cable will be suitable for any specified computer system without further testing. If you need any technique supports, please contact Thermaltake Global Service Center.
Core P90 TG Wall-Mounting Support
Apart from building Core P90 TG in horizontal/vertical
orientation, it’s an
optional feature to mount it on the wall to place your system in view like a work of art.
The wall-mounting
parts are not included.
Core P90 TG Radiator Supporting List
| Fan Compatibility List | |||
| 120mm | 140mm | 200mm | |
| Right | 4 | 3 | |
| Thermaltake Compatible Fan | |||
| 120mm | 140mm | 200mm | |
| Pure Fan Series |
*
|
*
|
- |
| Luna Fan Series |
*
|
*
|
- |
| Riing Fan Series |
*
|
*
|
- |
Core P90 TG Fan Supporting List
| Radiator Compatibility List | |||||||
| 120 mm |
140 mm |
360 mm |
140 mm |
280 mm |
420 mm |
480 mm |
|
| Right |
*
|
*
|
*
|
*
|
*
|
*
|
*
|
| All-in-One Compatibility
List (Water 3.0 and Floe series) |
||||||
| Performer | Pro | 240 Series | 360 Series | 140 Series | 280 Series | |
| Right |
*
|
*
|
*
|
*
|
*
|
*
|
| P/N | CA-1J8-00M1WN-00 |
|---|---|
| Series | Core |
| Case Type | Mid Tower |
| Dimension (H x W x D) | 470 x 470 x 615 mm (18.5 x 18.5 x 24.2 inch) |
| Net Weight | 17.2 kg / 37.9 lb |
| Side Panel | 5mm Tempered Glass x 2 (Left & Right) |
| Color | Black |
| Material | SPCC |
| Cooling System | - |
| Drive Bays -Accessible -Hidden |
3 x 2.5’’ (HDD Bracket) ; 2 x 3.5” or 2 x 2.5” (Optional) 2 x 3.5’’ or 2 x 2.5’’ (Behind the M/B tray) |
| Expansion Slots | 8 |
| Motherboards | 6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) |
| LCS Upgradable | - |
| I/O Port | USB 3.0 x 2, USB 2.0 x 2, HD Audio x 1 |
| PSU | Standard PS2 PSU (optional) |
| Fan Support | Right Side: 4 x 120mm 3 x 140mm |
| Radiator Support | Right Side: 1 x 480mm 1 x 420mm |
| Clearance | CPU cooler height limitation: 180mm VGA length limitation: 320mm PSU length limitation: 220mm |
User Manual
- File Name
- Description
- Size
- Version
- Release Date
-
Manual
- Multi-language
- 10.5 MB
- 2017-09-20
